17-4PH STAINLESS STEEL CONSTRUCTION
COMBINED ERROR < +/- 0,07%
IP67 PROTECTION RATING
ADJUSTABLE HEIGHT
| Specification | Value |
| Material | 17-4 PH stainless steel |
| Nominal load | 75-150-300-500-1000-2000-5000-10000 kg |
| Combined error | ≤±0.07% |
| Protection rating | IP67 |
| Rated output | 2.0 mV/ ±5% |
| Temperature effect on zero | 0.002%“C |
| Temperature effect on span | 0.002% C |
| Compensated temperature range | -10℃C/+50°C |
| Operating temperature range | -20°C/+60C |
| Creep at nominal load in 30 minutes | 0.02% |
| Max supply voltage without damage | 20 VDC |
| Input resistance | 350Ω±20 |
| Output resistance | 350 Ω +5 |
| Zero balance | 士1% |
| Insulation resistance | >5000 MΩ |
| Safe overload (% of full scale) | 120% |
| Ultimate overload (% of full scale) | 200% |
| Deflection at nominal load | 0.1 mm |
